16000 SERVICE/MAINTENANCE MANUAL HYDRAULIC SYSTEM
2
FIGURE 2-16
1
2
4
3
Item Case Drain Ports
1 Swing Motor (2 places)
2 Load Drum Motor (1 or 2 places each drum)
3 Boom Hoist Motor (2 places)
4 Travel Motor (2 places)
Item Brake Solenoid Valves
5 Electric Connector (typical)
6a Swing
7a Travel
8a Load Drum (typical 1 motor each)
9a Boom hoist (1 motor)
5
5 8a
7b
6b
57a6a
8b
9b
9a
Item Brakes
6b Swing (2 places)
7b Travel (2 places)
8b Load Drum (1 or 2 places each drum)
1
9b Boom Hoist (2 places)
1
1 Brakes are Inside Gear Boxes
P2299
P2270a
P2297
P2298
P2252
P2300
