INTRODUCTION 16000 SERVICE/MAINTENANCE MANUAL
1-8
Published 05-09-17, Control # 014-28
P2309
A1040-26
FIGURE 1-4
P2249a
P2282
14
13
16
15
10
11
9
8
12
P2252A
18
17
1
2
3
6
7
4
5
Right Side
Item Description
1 Jacking Cylinder Pads
2 Engine Oil Fill
3 Hydraulic Oil Return Filters
4
Hydraulic Tank Breather (past
production)
5 Tank Access Cover (16001141 and prior)
6Drum 2
7 Charge Filters (16001141 and prior)
8 Fuel Filter
9 Coolant Filter
10 Ether Starting Aid Canister
11 Node-5 Controller
12 Engine Air Cleaner
13 Air Cleaner Service Indicator
14 Wireless Radio Receiver
15 Engine Node-0
16 Oil Filter
17 Swing Motor (two)
18 Swing Gearbox (two)
