Manitowoc 16000 Service And Maintenance Manual

Reference Only
Manitowoc Published 05-09-17, Control # 014-28 3-25
16000 SERVICE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
Jib Node 21 — Block-Up, Load Pin, And Wind Speed
Reference Electrical Schematic A10871, Sheet 1, 11 and 21.
*Packet number depends on specific attachment used.
CAN ID. No.
Function
Type
Description Test Voltage
Packet
Code No.
J1 Receptacle – CAN In (From Jib Butt)
211-A 24 Volts CAN BUS System 24 Volts Nominal
211-B AI-NS Node Select AI-NS Node Select Jumper to GND
211-C CANH CAN High Wire Transmission N/A
211-D Ground CAN BUS System Ground
211-E Ground Node Select Ground to AI-NS Ground
211-F CANL CAN Low Wire Transmission N/A
J2 Receptacle – Upper Block Up
212-A 24 Volts Block Up Limit Luffing/Fixed Jib Upper Pt. 24 Volts Nominal
212-B DI-2 Block Up Limit Luffing/Fixed Jib Upper Pt. 0 Volts Off; 24 Volts On CAN113-6-128*
J3 Receptacle – Lower Block Up
213-A 24 Volts Block Up Limit Luffing Jib Lower Point 24 Volts Nominal
213-B DI-1 Block Up Limit Luffing Jib Lower Point 0 Volts Off; 24 Volts On CAN113-6-64*
J4 Receptacle – CAN Out
214-A 24 Volts CAN BUS System 24 Volts Nominal
214-C CANH CAN High Wire Transmission N/A
214-D Ground CAN BUS System Ground
214-E DI-ID Last Node Terminating Plug 24 Volts Nominal
214-F CANL CAN Low Wire Transmission N/A
J8 Wind Speed Indicator
218-A AI-3 Wind Speed Sensor .05 to 16 Volts DC
218-B Ground Wind Speed Sensor Ground
Jib Angle Indicator
Wire 1 Ground Jib Angle Indicator Ground
Wire 2 Signal Jib Angle Indicator Variable 0 to 5 Volts
Wire 3 5 Volts Jib Angle Indicator 5 Volts Nominal
