Manitowoc 16000 Service And Maintenance Manual

Reference Only
HOISTS 16000 SERVICE/MAINTENANCE MANUAL
5-8
Published 05-09-17, Control # 014-28
A1007
A1131
FIGURE 5-5
Right Hand Shown
Left Hand Opposite
From Boom or Jib
Node Controller
Dimension A
1.04 in (26 mm)
A1050
Limit Switch for
Lower Boom Point and Jib Point
Item Description
1 Elbow with Cord Gripper
2Setscrew
3Spring
4Enclosure
5 Adjusting Screw
(Spring Tension)
6 Grease Fitting
7 Actuating Lever
8Roller
9 Limit Switch Lever
10 Shaft
11 Cover
6
5
11
7
4
3
2
1
10
9
8
