POWER TRAIN 16000 SERVICE/MAINTENANCE MANUAL
7-4
Published 05-09-17, Control # 014-28
FIGURE 7-3
P2237a
Right Side of Upperworks
3
2
1
8
1a
7
3
4
6
5
Item Description
1 Air Cleaner Assembly
1a
Evacuator
™ Valve
1b Service Cover
1c Latch
1d O-Ring
1e Primary Filter
1f Safety Filter
1g Housing
2Inlet Cap
3Clamp (11 each)
4 Rubber Reducer
5 Rubber Elbow (4 each)
6Engine Intake
7 Mounting Bands
8 Service Indicator
8a Service Window
8b Reset Button
1b
8
8a
8b
1a
1b
1c
1d 1e 1f 1g
1b
1c
1a
5
A02258
A10577
3
