Manitowoc 16000 - Page 253

Reference Only
Manitowoc Published 05-09-17, Control # 014-28 8-7
16000 SERVICE/MAINTENANCE MANUAL UNDER CARRIAGE
8
S135
S137
S138
Notch in Dipstick
(Enerpac Pump)
FIGURE 8-4
Hose
Cylinder
Vent/Fill Cap
(Simplex Pump)
Extend
Cylinder
Close
Valve
Open
Valve
Retract
Cylinder
Pump
OR
