Operating elements for driving
3.2 Short description of the operating elements
Operating Manual GMK6300L 3 112 xxx en 3 - 45
xx.xx.xxxx
Error/warning message
Opening the Error submenu
The lamp (1) lights up or flashes.
Opening the Warning submenu
The lamp (1) lights up or flashes.
Exiting the submenu/input mode
The lamp (1) lights up.
Input confirmation
The lamp (1) lights up.
Entering values
Input mode is switched on.
s
Flashing: New warning message or error has occurred
–On: Error acknowledged – but still present
Off: No warning message or error present
à p. 11 - 114
To open: Press button once – submenu opens
à p. 11 - 114
To open: Press button once – submenu opens
à p. 5 - 48
Press the button
once:
The opened submenu closes – the menu from the
next higher level is opened
Input mode is deactivated
Press the button
once:
A newly entered value is saved
To the right: Increases the value
To the left: Decreases the value
Slow turning changes the value slowly
Fast turning changes the value fast
