Manitowoc Grove GMK6300L-1

Starting the engine for driving / switching it off
4.1 Starting the engine from the driver's cab
Operating Manual GMK6300L 3 112 xxx en 4 - 21
xx.xx.xxxx
4.1.12 Monitoring submenu
The Monitoring submenu provides an overview of the most important
measured values.
• If necessary, open the main menu ö and press the button (1) once.
This opens the
Monitoring submenu.
The following values are displayed:
The colour of the bar below the values indi-
cates the area in which the value can be found.
1 The hydraulic oil temperature in °C (°F)
2 Carbamide supply in percent
3 Voltage in volts
4 The transmission oil temperature in °C (°F)
Green: Value OK.
Yellow: Limit value almost reached
Red: Limit value exceeded (or not reached) – warning message;
à p. 5 - 48.
