Operating elements for driving
3.2 Short description of the operating elements
3 - 64 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
3.2.16 Level adjustment system
à Operating the level adjustment system, p. 5 - 64.
Level adjustment system submenu
Overall level pre-selection
The following functions are operated in the same manner:
– Front level pre-selection
– Rear level pre-selection
– Left level pre-selection
– Right level pre-selection
Lowering/raising the level
Suspension struts are pre-selected.
Movement stops after the button is released and when an end position is
reached.
– To open: Press button once – submenu opens
– Pre-selecting
suspension
struts:
Press button once – dot (1) turns green – pre-selection
on
After 5 seconds – dot (1) turns black – pre-selection off
à p. 5 - 65
1 Lowering: Press button – suspension struts retract
2Raise: Press button – suspension struts extend
à p. 5 - 66
