Operating elements for driving
3.2 Short description of the operating elements
3 - 52 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
3.2.10 Transfer case
In the main menu
Transfer case for off-road gear on/off
In the
Settings submenu
Neutral position transfer case on
Transfer case display
The current status is shown using different
symbols:
The displays in the main menu (6) and the
Settings submenu (5) always show the same
symbol.
– To switch on: Press button once – dot (1) green
– To switch off: Press button once – dot (1) black,
or
switching to neutral position
à p. 5 - 60
– To switch on: Press button once – display symbol (1)
– To switch off: Switch the off-road gear on/off
à p. 7 - 8
1 Off-road gear on
2 Off-road gear off – on-road driving
3 Select neutral
4 Error – violet
