Manitowoc Grove GMK6300L-1

Driving modes
6.6 Installing/removing the supporting box
Operating Manual GMK6300L 3 112 xxx en 6 - 85
xx.xx.xxxx
6.6.12 Transporting the supporting box on the separate vehicle
•
Check that the outrigger beams are secured against extension during
transportation with the locking pin;
à p. 12 - 32.
• Move the outrigger pads into operating position; à p. 12 - 39.
• Load the supporting box in such a way that other traffic is not endangered.
• Secure the supporting box and mounting equipment with holding ropes
to prevent them from falling from the transport vehicle, slipping or
damaging other parts.
• Load the transport vehicle in such a way that the weight is evenly
distributed.
• Transport the supporting box only on a separate vehicle of sufficient
lifting capacity;
à Dimensions and weights of removable parts, p. 1 - 10.
Lashing eyelets
• Fasten the supporting box for the transport
to the lashing eyelets (1) with holding ropes.
S
Risk of damage to add-on parts on the supporting box and outrigger pads!
Always secure the supporting box against slipping and overturning.
This will prevent damage.
G
Risk of accidents if used improperly!
For transport, attach the supporting box to the provided lashing eyelets
only and only use lifting gear of sufficient lifting capacity.
