Operating elements for crane operation
9.2 Short description of the operating elements
9 - 78 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
9.2.13 Main hoist
à Main hoist, p. 11 - 54.
Main hoist on/off
There is a lamp in the button.
Power units display
Right control lever
– Press once: – Lamp bright – main hoist on
– Lamp dim – main hoist off
à p. 11 - 55
–Green: Main hoist on
–Red: Main hoist off
– Back: Lifting
–Forward: Lowering
à p. 11 - 55
