Driving modes
6.7 Rigging the auxiliary hoist
6 - 98 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
6.7.8 Creating the connection to the turntable
The respective button combination required is shown in black.
Establishing the
connection
Lifting the auxiliary hoist
• Press the buttons (3) and (4).
Press the buttons (2) until the locking points (1)
are aligned.
G
Risk of being crushed when rigging the auxiliary hoist!
Make sure that you or any helpers keep all parts of the body a sufficient
distance away from the auxiliary hoist when rigging the auxiliary hoist.
Remove all objects in the rigging range that could become jammed or
crushed!
