Driving
5.1 Before driving
Operating Manual GMK6300L 3 112 xxx en 5 - 9
xx.xx.xxxx
Warning plates for
vehicle width
Depending on the vehicle width, fold-up warning plates are fitted below the
driver's cab.
The warning plates (1) must be folded down to
indicate the vehicle width during on-road
driving.
For off-road driving, the warning plates can
be folded up and fastened with the spring
latch (2).
Displaying vehicle
height
The vehicle height given at on-road driving level is only maintained when
the main boom is resting in the boom rest;
à p. 1 - 8.
• Open the main menu.
When the display (1) is present, the position of the main boom in the boom
rest is monitored.
• Check that the symbol (1) is shown.
• When the symbol (2) is shown, derrick the main boom out until the
symbol (1) appears.
s
S
Risk of accidents by exceeding total permissible height!
Check that the symbol
x is displayed.
Otherwise the indicated total height will also be exceeded at on-road level.
