Driving modes
6.5 Installing/removing outrigger beams
Operating Manual GMK6300L 3 112 xxx en 6 - 49
xx.xx.xxxx
6. Sling the outrigger beam and pull it out of the supporting box until it
reaches the centre of gravity;
à p. 6 - 59.
7. – Sling the outrigger beams in the centre of gravity and pull them out
of the supporting box.
– Lift the outrigger beams onto the separate vehicle.
– Attach the connecting elements on the supporting box.
à Extending the outrigger beam, p. 6 - 59
à Transporting the outrigger beams, p. 6 - 63
8. Remove all necessary outrigger beams in the same way in accordance
with this checklist.
