Driving modes
6.6 Installing/removing the supporting box
6 - 78 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
Lifting • Raise the main boom until you are able lift the supporting box upwards in
an upright position.
If the supporting box is to be placed on a separate vehicle:
• Move the separate vehicle up to the truck crane so that you can set down
the supporting box without overriding the RCL;
à p. 6 - 85.
Do not override the RCL!
• Lift the supporting box vertically out of the
carrier retainers (1) with the truck crane.
• Hold the supports (1) and remove the retain-
ing pins (2).
• Extend the supports (1).
• Secure the supports (1) by inserting the lock-
ing bolts (2) into the upper hole.
• Bring the outrigger pad (2) to the working-
position;
à p. 12 - 39.
