Driving modes
6.7 Rigging the auxiliary hoist
6 - 90 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
3. Slew the superstructure into the 0° to the rear position;
à Slewing with rigged counterweight, p. 12 - 83,
à The current slewing angle, p. 11 - 35.
4. Hang the ladder for rigging work on the counterweight;
à Ladder on the counterweight, p. 12 - 121.
5. – Establish the hydraulic connections;
à p. 6 - 96.
– Establish the electrical connection;
à p. 6 - 97.
6. Connect the hand-held control at the right rear of the turntable;
à Connecting/disconnecting the hand-held control, p. 12 - 21.
7. Creating the connection to the turntable:
– Lift the auxiliary hoist;
à p. 6 - 95.
– Create the connection to the turntable;
à p. 6 - 98.
– Lift the lifting frame;
à p. 6 - 98.
8. – Check that the auxiliary hoist is functioning properly;
à p. 6 - 103.
– Place the hoist rope on and reeve it.
