Driving modes
6.7 Rigging the auxiliary hoist
6 - 92 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
5. – Disconnect the hydraulic connections; à p. 6 - 96.
– Disconnect the electrical connections;
à p. 6 - 97.
6. Remove the ladder from the counterweight;
à Ladder on the counterweight, p. 12 - 121.
7. – Attach the auxiliary hoist at the centre of gravity;
à p. 6 - 98.
8. – Lift the auxiliary hoist onto the separate vehicle and make it ready for
transportation;
à p. 6 - 102.
9. If necessary, remove the rigging frame;
à p. 6 - 94.
