Malfunctions in driving mode
7.5 Fuses
7 - 24 3 112 xxx en Operating Manual GMK6300L
xx.xx.xxxx
Group F9
Group F10
Designation Amperage (A) Function
F9/1 3 Radio
F9/2 5 Radio
F9/3 15 Outrigger lighting
F9/4 10 Cigarette lighter, ceiling light
F9/5 15 Battery preheater
1)
F9/6 5 Battery preheater timer
1)
F9/7 Unassigned
F9/8 5 Auxiliary heater timer
1)
Designation Amperage (A) Function
F10/1 2 Daytime driving light, left
F10/2 2 Daytime driving light, right
F10/3 7.5 Reserve
F10/4 7.5 Reserve
F10/5 Unassigned
F10/6 Unassigned
F10/7 Unassigned
F10/8 Unassigned
1)
Additional equipment
