Operating elements for crane operation
9.2 Short description of the operating elements
Operating Manual GMK6300L 3 112 xxx en 9 - 85
xx.xx.xxxx
Derricking gear/telescoping mechanism high-speed mode on/off
The parking brake must be applied.
High-speed monitoring for derricking gear / telescoping mechanism
Raise button, shutdown bypassed
–Left: High-speed mode on, off when released
– Once to the right: High-speed mode on – continuous operation
– Once to the right or
once to the left:
High-speed mode off
à p. 11 - 94
–On: High-speed mode on
– Off: High-speed mode off
à p. 11 - 94
–On: Shutdown bypassed
– Off: Shutdown not bypassed
à p. 11 - 43
