Rigging work
12.7 Rigging/unrigging the counterweight
Operating Manual GMK6300L 3 112 xxx en 12 - 61
xx.xx.xxxx
5. Open the Counterweight submenu; à p. 12 - 75.
6. Enter the current rigging mode with the presently rigged counterweight
version on the RCL;
à p. 11 - 23.
7. When the 3-sheave hook block is reeved:
– extend telescopic section VI by 50%.
8. Lift the counterweight sections off the counterweight platform, as
required by the respective driving mode;
à Driving modes, p. 6 - 1,
à Slinging points on the counterweight sections, p. 12 - 56.
