Malfunctions during crane operation
14.4 Finding and eliminating malfunctions
Operating Manual GMK6300L 3 112 xxx en 14 - 33
xx.xx.xxxx
s
801 1 Rigging state not confirmed à Confirming the rigging mode,
p. 11 - 29.
802 2 RCL is overridden Cancel override;
à p. 11 - 40.
803 3 Slewing gear switched on with
RCL code for working position
0°, 180° or Free-on-wheels
Switching off the slewing gear
814 1 Maximum permissible overall
height exceeded
1)
Retract or lower.
814 2 Maximum permissible overall
working radius exceeded
1)
Raise or retract.
814 3 Maximum permissible overall
slewing range exceeded
1)
Slew into a permissible working
range.
814 4 Shutdown range of a moni-
tored object reached
1)
Move into a permissible working
range.
Error code Cause Remedy
1)
With working range limiter switched on
