106 Operator Maintenance
_______________________________________________________________________________________________
________________________________________________________________________________________________
MICROPLEX Operator’s Manual SOLID F90 HD Edition 1.0
1. Turn off the printer and pull the power plug.
2. Open the front cover of the printer.
Handhold
Fron
cover
3. Turn the lever of the developer unit clockwise until it points
up. The developer unit wi
ll be separated f
rom the photo-
receptor drum by this operation.
Lever
Developer uni
Pay attention to a correct performance of this operation to avoid
damaging the photoreceptor drum in the following steps.
