Troubleshooting 143
_______________________________________________________________________________________________
________________________________________________________________________________________________
MICROPLEX Operator’s Manual SOLID F90 HD Edition 1.0
8. After having removed the jammed paper:
- Turn knob "B" 90° counterclockwise back to his
original position (Lock).
- Press down the green lever to slide the transport unit into the
printer until it stops while pressing down the lever (resilience
at the end).
- Tip up the green lever of the transport unit to its "up"
position.
Pay attention to the second bar
of the transport unit
located under the green lever - it also has to click
into place (second bar up).
Second bar up
Green lever
