– 3.30 –
The distance between TP2 and TP1
The distance between registration marks(blank space) should be somewhere between the mark
length and 1000mm.
The size of the marks including all four sides
When in use of a wider (800mm, or wider) sheet, set in 210mm x 297mm to 297mm x 420mm size
including four sides of the registration marks. It enables to the wasteful margins to place efficiently
the image. *1
*1 : Depends on the size of the image, restrictions above may not be applied.
Between 50 and 9000mm
Between 50 and 9000mm
Between mark length(a)
and 1000mm
Between mark length(a)
and 1000mm
Approximately
210mm x 297mm
to
297mm x 420 mm size.
