Sensor Calibration Maintenance
7 - 8 046-003777-00 A5/A3™ Operating Instructions
10. Select the Begin button to start 100 % O
2
sensor calibration. The system will indicate the
calibration status when the process is completed. If an error code in red (e.g., 00 00 00 10) is
displayed, see TABLE7-2, “O
2
Sensor Calibration Error Codes,” on page7-8 for
troubleshooting information.
11. After calibration, select Done to close the calibration window.
NOTE: In case of repeated calibration failures, replace the O
2
sensor and
repeat the calibration. If calibration still fails, contact Mindray Technical
Support.
NOTE: The error code can be a combination of 2 codes e.g. 00 00 00 18 is 00 00
00 10 and 00 00 00 08.
ERROR CODE DESCRIPTION RECOMMENDED ACTION
00 00 00 01 O
2
sensor calibration is
canceled.
. Perform O
2
sensor calibration again.
00 00 00 02 O
2
supply pressure is low.
During 100 % calibration
process, O
2
supply pressure
was not sufficient.
. Check that the O
2
sensor is connected to the cable
correctly.
. Check the O
2
supply pressure.
. Check that the O
2
sensor output voltage in the
calibration menu is steady.
. Replace the O
2
sensor.
00 00 00 04 O
2
sensor is disconnected.
Sampled data is greater
than 2900 (AD value).
. Check that the O
2
sensor is connected to the cable
correctly.
. Check that the O
2
sensor output voltage in the
calibration menu is steady.
. Replace the O
2
sensor.
00 00 00 08 21 % calibration value is
outside of the expected
range (150~500)
(AD value).
. Check that the O
2
sensor is connected to the cable
correctly.
. Check that the O
2
sensor is in 21 % O
2
.
. Check that the O
2
sensor output voltage in the
calibration menu is steady.
. Replace the O
2
sensor.
00 00 00 10 100 % calibration value is
outside of the expected
range (800~2028) (AD
value).
. Check that the O
2
sensor is connected to the cable
correctly.
. Check that the O
2
sensor is in 100 % O
2
.
. Check that the O
2
sensor output voltage in the
calibration menu is steady.
. Replace the O
2
sensor.
00 00 00 20 Error writing to EEPROM. . Repeat the calibration.
. Replace the O
2
sensor.
. Replace the CPU board.
TABLE 7-2 O
2
Sensor Calibration Error Codes

Mindray A5 Specifications

General

Type	Anesthesia Machine
Brand	Mindray
Model	A5
Power Supply	100-240 V AC, 50/60 Hz
Ventilation Modes	SIMV, PSV
Flowmeters	O2, N2O, Air
Vaporizer Capacity	Up to 3 vaporizers
Safety Features	O2 failure protection, low pressure alarm
Gas Module	Optional integrated gas module
Integrated Air Compressor	Optional
Patient Monitoring	Integrated monitoring with optional modules
