Mindray A5 Operating Instructions

Cleaning and Disinfection Maintenance
7 - 24 046-003777-00 A5/A3™ Operating Instructions
FIGURE 7-21 Gasket installation
WARNING: Use extreme care while handling the absorbent as it contains a caustic
irritant.
WARNING: Check if the gasket is properly installed in place while installing the
absorber canister. If the gasket is not properly installed (for example,
gasket is not evenly seated and centered) it may cause breathing
system leakage.
WARNING: Ensure that the absorber canister is completely dry before adding
absorbent.
7. While noting the previous WARNING, add new Pre-Pak or loose fill absorbent to the
absorber canister. Re-install the absorber canister into the assembly. Rotate the locking
mechanism handle clockwise into the locked position (see FIGURE 7-20). Prior to use after
cleaning or disinfecting, power up the system and follow the on-screen prompts to perform
the leak test and the compliance test (see section4.5 (page 4-9) "Leak and Compliance
Tests").
Correct installation
Correct
installation
Incorrect installation
Incorrect
installation

Mindray A5 Specifications

General

Type	Anesthesia Machine
Brand	Mindray
Model	A5
Power Supply	100-240 V AC, 50/60 Hz
Ventilation Modes	SIMV, PSV
Flowmeters	O2, N2O, Air
Vaporizer Capacity	Up to 3 vaporizers
Safety Features	O2 failure protection, low pressure alarm
Gas Module	Optional integrated gas module
Integrated Air Compressor	Optional
Patient Monitoring	Integrated monitoring with optional modules
