A5/A3â„¢ Operating Instructions 046-003777-00 3 - 5
System Interface Main Screen Components
14 System Softkeys Setup – Select to open the Setup menu. The Setup menu
contains the General tab, Display tab, System tab, and
Service tab.
Alarms – Select to open the Alarms menu to set alarm
limits, set alarm volume, and view all active alarms.
Silence – Select Silence softkey to silence all currently
sounding alarm tones. The alarm will sound if a new alarm
occurs.
If the silenced alarms contain middle or high level alarms,
the alarm audio will be paused for 120 seconds. The alarm
silence icon and 120 second countdown time appear at the
top of the screen. Select again to resume the alarm audio.
Note, however, the alarm will sound if that a new alarm
occurs while the system is in an audio-paused state. If this
occurs, you can select the Silence softkey again to silence
the new alarm and reset the silence countdown timer to
120 seconds.
Found in software bundle version 02.04.00 and later
If the silenced alarm is low level alarm, the alarm audio will
be turned off till a new alarm occurs. Note, however, the
alarm will sound if that a new alarm occurs while the
system is in an audio-off state. If the new alarm is low level
alarm, you can select the Silence softkey again to turn off
the new alarm audio. If the new alarm is medium or high
level alarm, you can select the Silence softkey again to
silence the new alarm for 120 seconds.
Found in software bundle version 02.02.00 and later
History - Select to open the History menu. The History
menu contains the List Trends and Event log.
Capture Event - Select to capture an event and log it in the
event log.
15 Gas Area Displayed when AG module is connected. Displays real-
time inspiratory and expiratory levels of gas.
16 Waveforms/Spirometry Area Displays waveforms or spirometry.
17 Monitored Parameter Area Displays monitored parameters.
NUMBER
MAIN SCREEN
COMPONENT DESCRIPTION
* Monitor mode is only available with the AG module.
**SIMV-PC and Bypass are only available on A5.
