8-24
8.11.3 12-Lead Setup
In the 12-lead screen, select [Setup] to enter the [12-Lead Setup] menu to change the settings related to 12-lead ECG
analysis. In the [12-Lead Setup] menu, you can also select [Report Setup>>] to set the format and contents of the ECG
reports.
12-lead Setup
Menu item Option Default Description
Filter Diagnostic, ST Diagnostic Set filter mode.
Note: The filter mode automatically switches to
[Diagnostic] when the patient monitor accesses the
12-lead -screen and resumes to the original setting
when the patient monitor exits the 12-lead screen.
Baseline Drift
Removal
On, Off On
Select whether the baseline drift removal (BDR)
process or 0.05-Hz filter is used.
[On]: BDR is enabled. This process suppresses most
baseline drift interference and also is able to
preserve the fidelity of the ST-segment level.
[Off]: BDR is disabled and the 0.05-Hz filter is used.
NOTE: BDR or 0.05-Hz selection applies to the
displayed ECG, printed report, analyzed and stored
data.
BDR introduces around 1-second delay. We
recommend use of BDR except when the delay is
unacceptable.
Both BDR and 0.05-Hz selections meet requirements
of the 1990 American Heart Association
Recommendations for Standardization and
Specifications in Automated Electrocardiography:
Bandwidth and Signal Processing pertaining to
lower-frequency response in electrocardiography.
Tachy High 80 - 130 100 Adjusts tachycardia threshold. Heart rates above the
setting are labelled Tachycardia.
Only applies to patients whose age exceeds 180
days.
Brady Low 40 - 60 50
Adjusts bradycardia threshold. Heart rates below
the setting are labelled Bradycardia.
Only applies to patients whose age exceeds 2191
days.
QTc Formula Hodges, Bazett, Fridericia,
Framingham
Hodges Selects QTc formula.
Hodges:
6075.1 HeartRateQTQTc
Bazett:
2
1
60
HeartRate
QTQTc
