8-26
8.11.4 Resting 12-lead ECG Analysis
The Glasgow algorithm provides an interpretation of the resting 12-lead ECG in all situations.
Before 12-lead ECG interpretation, check that all electrodes are correctly connected to the lead wires and the ECG trunk
cable is properly connected. Check that patient information is correct.
To start analyzing, select the [Analyze] key. The resting 12-lead analysis takes about 10 seconds. During this period, keep
the patient still.
After analysis finishes, the following dialog-box pops out.
Select [Print Report] to pint the resting 12-lead ECG report from the external printer.
You can also print the latest 12-lead ECG report by selecting [Report] from the 12-lead screen.
Refer to12-Lead ECG Interpretive Program Physician’s Guide (PN: 046-006360-00) for details.
CAUTION
During the resting 12-lead ECG analysis, keep the patient still. Patient movement may cause misdiagnosis.
NOTE
Glasgow resting 12-lead ECG intepretation is applied to adult, pediatric and neonate.
During 12-lead ECG analaysis, 12-lead related settings are disabled.
Changing patient information, including the patient’s age, date of birth, gender, race, medication, class, or
V3 placement setting,may change diagnosis statement. You shall select the [Analyze] key to reanalyze the
patient’s ECG before you print the latest 12-lead ECG report.
