Mindray BeneView T1 User Manual

A-4
A.4 Physical Specifications
Size Weight
Patient monitor
≤142 mm×81 mm×102 mm ≤1 kg
Battery
≤74 mm×47 mm×24 mm ≤0.15 kg
T1 handle
≤165 mm×130mm×168mm ≤1.6kg (with the T1 and battery)
T1 docking station
≤190mm×125mm×155mm ≤0.95kg
Sidestream CO
2
module
136.5×40×102 mm ＜0.60 kg
Microstream CO
2
module
136.5×40×102 mm ＜0.37 kg
Mainstream CO
2
module
136.5×40×102 mm ＜0.50 kg
PiCCO module
136.5×40×102 mm ＜0.28 kg
A.5 Hardware Specifications
A.5.1 Display
Host display
Screen type Color TFT LCD
Screen Size 5 inch
Resolution 480×272 pixels
External display
Screen type Color TFT LCD
Screen Size 19 inch
Resolution 800×600 pixels
A.
5.2 Equipment connector
Main unit
Multifunctional connector 1
DC input 1
Main unit multi-pin connector 1
T1 handle
T1 handle multi-pin connector 1 1
T1 handle multi-pin connector 2 1
Infrared filter 1
Contact 2
Pogo pin 3
T1 docking station
Network connector 1
Equipotential grounding terminal 1
AC power input 1
VGA connector 1
External device connector 1
USB connector: 2
T1 docking station multi-pin connector 1
