C-11
C.2.2 Screens
Item Name
Configurable
Default
In Config Mode In Monitor Mode
Choose Screen Yes Yes Normal Screen
Select Wave
Sequence for
Normal Screen
1
Yes Yes
ECG1
2 ECG2
3 SpO
2
+ PR
4 Any IBP
5 Any IBP
6 CO
2
7 Resp
Select Parameters
for Big Numerics
Screen
Parameter 1
Yes Yes
ECG
Parameter 2 SpO
2
+ PR
Parameter 3 Resp
Parameter 4 NIBP
C.2.3 Parameter/Wave Color
Item Name
Configurable
Default
In Config Mode In Monitor Mode
Parameter/
Wave Colour
ECG
No Yes
Green
NIBP White
SpO
2
Cyan
TEMP White
Art/Ao/UAP/FAP
/BAP/LV/P1~P4
(arterial pressure)
Red
CVP/ICP/P1~P4
(venous pressure)
Blue
CO
2
Yellow
RESP Yellow
Night Mode
Item Name
Configurable
Default
In Config Mode In Monitor Mode
Brightness No Yes 1
Alm Volume No Yes 2
QRS Volume No Yes 1
Key Volume No Yes 0
Stop NIBP No Yes Unselected
