System Overview 2-9
No. Name Function
<10>
Probe and ultrasound
gel holder
Used for temporarily placing probes or ultrasound
gel.
<11>
Control Panel Operator-system interface or control.
<12>
Frontal handle Used for pushing and moving the system.
<13>
Control table adjusting
handle
Lift and hold the handle to lift/down the control table,
or to turn the control table left / right.
<14>
Physiological-signal
panel
Used for connecting the ECG leads, footswitch, and
inputting ECG signal.
<15>
Probe ports
Sockets connecting probes and the main unit.
The lowest one is for 4D probes.
<16>
Table for placing
peripherals
Placing peripherals.
<17>
Rear handle
Used for lifting the machine, or managing the probe
cable.
<18>
Monitor support arm
Used for support and adjustment of height and
position of LCD monitor.
<19>
Heat rejection panel
Main unit heat rejection.
<20>
I/O Panel
Interface panel used for inputting and outputting
signals.
<21>
Power supply panel
Electrical port panel.
NOTE: Do not overexert to push down or lift up the control panel when operate the control
table adjusting handle.
