System Overview 2-13
status
indicator
z When the batteries are being charged, the
indicator light is on and in orange.
z When the battery capacity is charged to full
capacity, the indicator turns green.
z When the system is powered by the batteries
and the power capacity is more than 20%, the
indicator is green.
z When the system is powered by the batteries
and the power capacity is lower than 20%, the
indicator is orange and flashes.
z When the system is powered by the batteries
and the power capacity is lower than 5%, the
indicator is orange and flashes fleetly.
z In other statuses, the indicator light is off.
<3> / AC power
supply
status
indicator
Indicates if the main unit is connected to the AC power
supply.
If not connected, the indicator does not illuminate.
If connected, the indicator illuminates in green color.
<4> / Standby
status
indicator
When the system enters the standby status, the
indicator turns orange and flashes.
In other statuses, the indicator light is off.
<5> / Hard disk
status
indicator
When the hard disk is operated, the indicator turns
green and flashes.
In other statuses, the indicator light is off.
Note: When the indicator turns green, don’t move the
system. Otherwise, the hard disk may be damaged.
<6> Esc Exit Press to exit the current status to the previous status.
<7> F1 Help
Help
Press to open or close the accompanying help
documents.
<8> F2
iStation
/ Press to enter or exit the patient information
management system.
<9> F3 Eject / Press to eject the disc.
<10> F4-F6 User-
defined key
You can assign a function to the key.
<11> F7
QSave
/ Save image.
<12> F8 iZoom iZoom Enter/exit iZoom mode.
<13> F9 3D/4D 3D/4D Enter/exit 3D/4D.
<14> F10
Setup
Setup Enter setup.
<15> F11
Biopsy
Biopsy Enter/exit biopsy.
<16> F12
Arrow
Arrow Enter/exit arrow comment status.
