System Overview 2-15
<36> Body
Mark
Body Marks Press to enter or exit the Body Mark status.
<37> M(X)
Pressable
knob
Press to enter M mode, and rotate to adjust M gain;
while in 3D/4D mode, rotate the knob to make the 3D
image to rotate around X axis.
<38> PW(Y) Pressable
knob
Press to enter PW mode, and rotate to adjust PW (in
PW mode) or CW gain (in CW mode); while in 3D/4D
mode, rotate the knob to make the 3D image to rotate
around Y axis.
<39> Color(Z) Pressable
knob
Press to enter Color mode, and rotate to adjust Color (in
color mode) or Power gain (in Power mode); while in
3D/4D mode, rotate the knob to make the 3D image to
rotate around Z axis.
<40> B Pressable
knob
Press to enter B mode, and rotate to adjust B gain.
<41> Nav. Navigation Multi-function knob.
<42> Freeze Freeze Press to freeze or unfreeze the image.
<43> Back Back Press to return to the previous operation or delete the
previous item.
<44> Measure Measure Press to enter or exit the application measurement
mode.
<45> Update / Press to change the currently active window.
Or start/stop image acquisition in iScape or 3D/4D.
<46> Caliper Caliper Press to enter or exit the general measurement mode.
<47> Set
Set
Press to confirm an operation, same as the left-button
of the mouse.
<48> / Trackball Roll the trackball to change the cursor position.
<49> Dual
/
Enter Dual mode in Non-dual mode;
Switch between the two displaying windows in Dual
mode.
<50> Depth Depth Adjust depth in real-time imaging.
<51> P1 / User-defined key.
<52> Single / Enter into single displaying window from splitting mode.
<53> Zoom Zoom Rotate to enter the pan mode, and press to enter the
spot mode.
<54> Print Print Press to print, user-defined key.
<55> Save Save Press to save image, user-defined key.
