6In the Properties pane, select the appropriate element from the RS-422
communication port list.
When connected, the serial-port test agent will log all data received from the serial port
to a file that you can read using a Web browser.
Once the database is exported to the multiviewer, the serial-port test agent starts. The
agent opens the serial port and start writing to a log file the data that is received on the
port. To access the log file, point your browser to
http://[IP
address]/logs/comm.log
.
Note: The part [IP address] represents the IP address of the output card
(or of the multiviewer itself, depending on the model) where the test agent
is connected. You can find the IP address on XAdmin’s System Configuration
page (see
Configuring a Multiviewer’s IP Settings, on page 395).
