Mitsubishi FX3U Series User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
104
6 Examination of System Configuration
6.8 Number of Input/Output (Occupied) Points and Current Consumption
6.8.2 [B] Expansion boards
−: No need to calculate
*1. When FX
3U-422-BD is connected, add the current consumed by GOT/programming tool .
GOT/programming tool
−: No need to calculate
*1. When FX-20P-RWM is used, the current is 180 mA.
6.8.3 [C] Special adapters
−: No need to calculate
*1. When applying the DC power type main unit, calculate the current consumption at startup.
No. Type
Number of input/
output occupied
points
Current consumed (mA)
5V DC Internal 24V DC
FX3U-232-BD − 20 −
FX
3U-422-BD −
20
*1
−
FX
3U-485-BD − 40 −
FX
3U-USB-BD − 15 −
FX
3U-CNV-BD −−−
No. Type
Number of input/
output occupied
points
Current consumed (mA)
5V DC Internal 24V DC
FX-20P(-E)
−
150
*1
−
FX-10P(-E)
− 120 −
FX-232AW
− 220 −
FX-232AWC
− 220 −
FX-232AWC-H
− 120 −
FX-USB-AW
− 15 −
FX-10DM(-SET0)(-E)
− 220 −
F920GOT-BBD5-K(-E)
− 220 −
No. Type
Number of input/
output occupied
points
Current consumed (mA) Current
supply at
startup (mA)
*1
5V DC Internal 24V DC External 24V DC
FX
3U-4HSX-ADP − 30 30 0 30
FX
3U-2HSY-ADP − 30 60 0 120
FX
3U-4AD-ADP − 15 0 40 −
FX
3U-4DA-ADP − 15 0 150 −
FX
3U-4AD-PT-ADP − 15 0 50 −
FX
3U-4AD-TC-ADP − 15 0 45 −
FX
3U-232ADP − 30 0 0 −
FX
3U-485ADP − 20 0 0 −
B
B1
F
F
F1
C
C1
C2
C3

Mitsubishi FX3U Series Specifications

General

Model	FX3U Series
Program Memory	64k steps
Execution Speed	0.065 μs/basic instruction
Type	PLC (Programmable Logic Controller)
Power Supply	100-240V AC
I/O Points	Up to 384
Communication	USB
Expansion	Supported via expansion modules
High-Speed Counters	Up to 6 channels
Analog Input/Output	Available via expansion modules
Temperature Range	0 to 55°C
Programming Language	Ladder Logic, Structured Text
Built-in Functions	PID control
Humidity	5 to 95% (non-condensing)
