FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
19 FX3U-7DM (Display Module)
19.9 Error Check
19.8.2 Test mode operation
1) Perform a monitor mode operation to display the user-registered
device whose current value is to be changed.
→ Refer to Subsection 19.7.2 for monitor function operation.
2) Hold the [OK] button for 1 second or longer to switch to the test
mode. The current value then begins blinking (refer to fig. at right).
3) Use the [+] / [-] buttons to change the value as desired. To cancel
the operation and return to the "monitor screen", press [ESC].
4) Press [OK] to register the current value and return to the "user registered devices screen".
19.9 Error Check
The main unit’s error status displays at the "ErrorCheck" menu.
1) At the menu screen, use the [+] / [-] buttons to move the cursor to
the "ErrorCheck" item, then press [OK].
The error check result then displays at the "error display screen"
(refer to fig. at right).
To cancel the operation and return to the "top screen (time
display)", press [ESC] at the menu screen
2) If multiple errors have occurred, the [+] / [-] keys can be used to
switch between the error display pages.
Display Content
3) To cancel the operation and return to the "menu screen", press
[ESC].
Button Operation Description
ESC
Cancels the operation and returns to the "monitor
screen".
-
Reduces the value.
Hold for 1 second or longer for high-speed reduction.
+
Increases the value.
Hold for 1 second or longer for high-speed increase.
OK
Registers the current value and returns to the "monitor
screen".
Button Operation Description
ESC Returns to the "menu screen".
-
1 error or less Disabled
2 errors or more Displays the previous-page’s error screen.
+
1 error or less Disabled
2 errors or more Displays the next-page’s error screen.
OK Returns to the "menu screen".
Display Content
[1]
Active error flag
[2]
Error name
[3]
Error code
[4]
Number of concurrent errors
(displays only when multiple errors have occurred)
D 100
10
Ha l t t ime r
D 100
10
Ha l t t ime r
D 100
20
Ha l t t ime r
Eo
When no errors have occurred
rrrhC
When 1 error has occurred
M0866
6612
[1]
[2]
[3]
When multiple errors have occurred
M0806
1020
[1]
[2]
[3]
IO/
/12
M0836
6301
[1]
[2]
[3]
/22
[4]
[4]
+-
ekc
eorrrsoN
EorrrhCekc
EorrrhCekc
EorrrhCekc
Eorrrcoed
Eorrrcoed
Eorrrcoed
err
eorrrLddaer
eorrrLkni1
