16.1 Outline
Connect input/output extension blocks to the PLC to add more input/output points. 8 or 16 points can be
added by an input/output extension block.
Since the power is supplied from the main unit, it is not necessary to prepare another power supply unit for
each input/output extension block.
16.1.1 Product type
There are various types of input/output extension blocks. Select optimum blocks considering the input type,
output type, and connection unit of your system.
Input/output extension blocks
Input type
24V DC
(Sink, source)
Power supply
Power supply to
inside of PLC
Number of points
8
24V DC
(Sink)
100V AC system
5V DC
Connection unit
Terminal block
Connector
Output type
Relay
Triac
Transistor
(Source)
Transistor
(Sink)
16
