3 Introduction of Products (Compliant with Overseas Standards)
3.1 List of Products (to be Connected) and Interpretation of Model Names
1
Introduction
2
Features and Part Names
3
Product Introduction
4
Specifications
5
Version and Peripheral Devices
6
System Configuration
7
Input/Output Nos., Unit Nos.
8
Installation
9
Preparation and Power Supply Wiring
10
Input Wiring
3.1.4 [D] [E] Special function units/blocks
For details of each product, refer to the product manual.
1. Analog control
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
* Please consult with Mitsubishi Electric for information on marine standard practices and the
corresponding types of equipment.
→ For more information on CE, UL and cUL, refer to Page 15 or later.
2. High-speed counter
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
* Please consult with Mitsubishi Electric for information on marine standard practices and the
corresponding types of equipment.
→ For more information on CE, UL and cUL, refer to Page 15 or later.
Model name
Analog
Description
CE
UL
cUL
Marine
Input Output EMC LVD
Analog input
FX3U-4AD 4ch − Voltage/current input  −
FX
2N-2AD 2ch − Voltage/current input  *
FX
2N-4AD 4ch − Voltage/current input  *
FX
2N-8AD 8ch −
Voltage/current/temperature
(thermocouple) input
 *
FX
2N-4AD-PT 4ch −
Temperature (resistance
thermometer sensor) input
 *
FX
2N-4AD-TC 4ch −
Temperature (thermocouple)
input
 *
Analog output
FX3U-4DA − 4ch Voltage/current output  −
FX
2N-2DA − 2ch Voltage/current output  *
FX
2N-4DA − 4ch Voltage/current output  *
Analog input/output mixed
FX0N-3A 2ch 1ch Voltage/current input/output  − *
FX
2N-5A 4ch 1ch Voltage/current input/output  *
Temperature control
FX2N-2LC 2 loops −
Temperature control (resistance
thermometer sensor/
thermocouple)
 −
Model name Description
CE
UL
cUL
Marine
EMC LVD
FX
2N-1HC 1-ch high-speed counter  *
D
D

Mitsubishi FX3U Series Specifications

General

Model	FX3U Series
Program Memory	64k steps
Execution Speed	0.065 μs/basic instruction
Type	PLC (Programmable Logic Controller)
Power Supply	100-240V AC
I/O Points	Up to 384
Communication	USB
Expansion	Supported via expansion modules
High-Speed Counters	Up to 6 channels
Analog Input/Output	Available via expansion modules
Temperature Range	0 to 55°C
Programming Language	Ladder Logic, Structured Text
Built-in Functions	PID control
Humidity	5 to 95% (non-condensing)
