19.10 LANGUAGE (Menu Display Language Setting)
The language used at the display module menus is specified at the "LANGUAGE" menu. The language
setting procedure is described below.
All operation explanations and display screen examples in this manual are in Japanese. When the menu
display language is set to English, please convert the screen messages to their English translations.
→ Refer to Section 19.25 for the Japanese & English display character correspondence table.
19.10.1 Changing to Japanese menus
The procedure for changing from English menus to Japanese menus is described below.
1) Turn the PLC power on.
Following a brief title screen display (1.5 seconds), the "current time
screen" or a "user message" is displayed.
2) Press the [OK] button to display the menu screen shown to the right
(4 lines of the menu display).
3) At the menu screen, use the [+] / [-] buttons to move the cursor to the
"LANGUAGE" item, then press [OK] to display the "display language
selection screen".
To cancel the operation and return to the "top screen (time display)",
press [ESC].
Top screen (Time display)
Approx.
1.5 secs.
Title screen
User creation screen (example)
or
FX3U Se r i e s
MELSEC - F
Ve r . 2 . 00
05 . 5 .31
23: 59: 59 [ e]Tu
0T a r e t
< P r o
g
d u i ot >c
R e m i n na g
n
P r o d u i otc n
0
01
09i
01 0
0
9 0
Mon tor
ErrorC
LANGUA
h
GE
Contra
EntryC
ClearAllDev
PL
Sca Timn
Cas etts
i / estT
eck
st
ClockMenu
ode
C Status
e
e
LGNAUGAE
nEg ilsh
To Next Page
