FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
379
19 FX3U-7DM (Display Module)
19.16 Scan Time (Scan Time Display)
11
High-Speed
Counters
12
Output Wiring
13
Wiring for
Various Uses
14
Test Run,
Maintenance,
Troubleshooting
15
IInput/Output
Powered
Extension Units
16
Input/Output
Extension
Blocks
17
Extension
Power Supply
Unit
18
Other Extension
Units and
Options
19
Display Module
20
Terminal Block
3. PLC Status 3/3
19.16 Scan Time (Scan Time Display)
The scan time’s current value, minimum value, and maximum value can be displayed from the "ScanTime"
menu.
19.16.1 Scan time display operation
1) At the menu screen, use the [+] / [-] buttons to move the cursor to
the "ScanTime" item, then press [OK] to display the "scan time
screen".
To cancel the operation and return to the "top screen (time
display)", press [ESC].
2) Press [OK] or [ESC] to return to the "menu screen".
19.17 Cassette (Memory Cassette Transfers)
Data transfers (and consistency checks) between the internal RAM memory and a connected memory
cassette can be performed from the "Cassette" menu when the PLC is in a STOP state.
This menu is disabled, however, if an entry code is registered in the internal RAM. In this case, remove the
memory cassette and use the programming tool to cancel the internal RAM’s entry code.
Display Content
[1]
Battery voltage
[2]
Number of registered comments
([number of registered comments] / [number of parameter-specified comments])
Item Operation Description
Cassette←RAM Copies internal program memory (RAM) data to a connected memory cassette.
Cassette→RAM Copies data from a connected memory cassette to the internal program memory (RAM).
Cassette : RAM
Performs a consistency check of the connected memory cassette data and the internal
program memory (RAM) data.
[1]
[2]
00/ 002001
taBte .2V3
tnes
PL a utsCtS(/33)
ry
moCm
SncTima
:ms.70
:ms.65
:ms.60
e
rCru
xMa
nMi
To Next Page
