FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
15 FX2N-32/48E*-* (Input/Output Powered Extension Units)
15.2 Power Supply Specifications (Power Supply Input/24V DC Service Power Supply)
15.2 Power Supply Specifications
(Power Supply Input/24V DC Service Power Supply)
15.2.1 Weight, accessories, etc.
Item
FX2N-32ER-ES/UL
FX
2N-32ET-ESS/UL
FX2N-32ER
FX
2N-32ES
FX
2N-32ET
FX2N-48ER-ES/UL
FX
2N-48ET-ESS/UL
FX2N-48ER
FX
2N-48ET
Classification FX2N powered extension unit
Supply voltage 100 to 240V AC
Allowable supply voltage range 85 to 264V AC
Rated frequency 50/60 Hz
Power fuse 250V 3.15 A(3 A) 5φ x 20mm (0.79") 250V 5 A 5φ x 20mm (0.79")
Rush current
100V AC Up to 40 A, 5 ms or less
200V AC Up to 60 A, 5 ms or less
Power consumption 30 W (35 VA) 35 W (45 VA)
24V DC
service power
supply
Without extension
block
24V DC, 250 mA or less 24V DC, 460 mA or less
With extension
block
When input/output extension blocks are connected, 24V DC service power is
consumed by them.
→ For details, refer to Section 6.6.
Connection type Removable terminal block (M3 screw)
Item FX2N-48ER-UA1/UL
FX2N-48ER-DS
FX
2N-48ET-DSS
FX2N-48ER-D
FX
2N-48ET-D
Classification FX2N powered extension unit
Supply voltage 100 to 240V AC 24V DC
Allowable supply voltage range 85 to 264V AC +20%, -30%
Power fuse 250V 5 A 5φ × 20mm (0.79")
Rush current
100V AC Up to 40 A, 5 ms or less −
200V AC Up to 60 A, 5 ms or less −
Power consumption 35 W (45 VA)
24V DC service power supply None
Connection type Removable terminal block (M3 screw)
Item
FX2N-32ER-ES/UL
FX
2N-32ET-ESS/UL
FX2N-32ER
FX
2N-32ES
FX
2N-32ET
FX2N-48ER-ES/UL
FX
2N-48ET-ESS/UL
FX
2N-48ER-DS
FX
2N-48ET-DSS
FX2N-48ER
FX
2N-48ET
FX
2N-48ER-D
FX
2N-48ET-D
FX2N-48ER-
UA1/UL
Weight 0.65 kg (1.43 lbs) 0.85 kg (1.87 lbs) 1.00 kg (2.2 lbs)
Accessories
• Terminal protective cover (2 pcs.)
(Fitted to FX
2N-32ER-ES/UL, FX2N-32ET-ESS/UL, FX2N-48ER-ES/UL, FX2N-48ET-ESS/UL and
FX
2N-48ER-UA1/UL, FX2N-48ER-DS, FX2N-48ET-DSS)
• Extension cable (55 mm (2.16"))
Optional extension cables (FX
0N-30EC and FX0N-65EC) are available.
• Input/output number label
Others
• The terminal block uses M3 terminal screws.
• Installation of the DIN46277 (35 mm (1.37") wide) rail or screws.
