Mitsubishi FX3U Series User Manual

467
FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
Revised History
Revised History
Date Revision Discription
7/2005 A First Edition
2/2006 B • The following products are added:
- Main unit of transistor output type
FX
3U-16MT/ES, FX3U-16MT/ESS, FX3U-32MT/ES, FX3U-32MT/ESS,
FX
3U-48MT/ES, FX3U-48MT/ESS, FX3U-64MT/ES, FX3U-64MT/ESS,
FX
3U-80MT/ES, FX3U-80MT/ESS
Contents are added to product introduction (Chapter 3), specifications, external
dimensions, terminal layout (Chapter 4), examination of system configuration
(Chapter 6), wiring examples for each purpose (Chapter 13), etc.
- Main unit of AC power type
FX
3U-128MR/ES, FX3U-128MT/ES, FX3U-128MT/ESS
- Main unit of DC power type
FX
3U-16MR/DS, FX3U-16MT/DS, FX3U-16MT/DSS
FX
3U-32MR/DS, FX3U-32MT/DS, FX3U-32MT/DSS
FX
3U-48MR/DS, FX3U-48MT/DS, FX3U-48MT/DSS
FX
3U-64MR/DS, FX3U-64MT/DS, FX3U-64MT/DSS
FX
3U-80MR/DS, FX3U-80MT/DS, FX3U-80MT/DSS
Contents are added to product introduction (Chapter 3), specifications, external
dimensions, terminal layout (Chapter 4), examination of system configuration
(Chapter 6), installation in enclosure (Chapter 8), example of power supply wiring
(Chapter 9), example of input wiring (Chapter 10), example of output wiring
(Chapter 12), etc.
- Input/output powered extension unit of DC power type
FX
2N-48ER-DS, FX2N-48ET-DSS, FX2N-48ER-D, FX2N-48ET-D
Contents are added to product introduction (Chapter 3), examination of system
configuration (Chapter 6), installation in enclosure (Chapter 8), example of power
supply wiring (Chapter 9), input/output powered extension units (Chapter 15), etc.
- 8-point type input/output extension block
FX
2N-8ER-ES/UL, FX2N-8ER, FX2N-8EX-ES/UL, FX2N-8EX, FX2N-8EX-UA1/UL,
FX
2N-8EYR-ES/UL, FX2N-8EYR, FX2N-8EYT-ESS/UL, FX2N-8EYT,
FX
2N-8EYT-H
Contents are added to product introduction (Chapter 3), examination of system
configuration (Chapter 6), input/output extension block (Chapter 16), etc.
- Special function blocks
FX
3U-4AD, FX3U-4DA, FX3U-20SSC-H
Contents are added to product introduction (Chapter 3), examination of system
configuration (Chapter 6), installation in enclosure (Chapter 8), other extension
devices (Chapter 18), etc.
- Extension power supply unit
FX
3U-1PSU-5V
Contents are added to product introduction (Chapter 3), examination of system
configuration (Chapter 6), installation in enclosure (Chapter 8), example of power
supply wiring (Chapter 9), etc.
Chapter 17 added for Extension power supply unit
• Ver. 2.30 is supported.
- Two types of instructions are added (Appendix B-1).
For the details of instructions, refer to the programming manual.
- Special auxiliary relays and special data registers are added (Appendix A).
• Cautions on write during RUN are added (Subsection 5.2.4).
• The applicability of other peripheral equipment is added (Section 5.5).
5/2006 C • EN61131-2:2003 added to EMC directive and LVD directive in FX
2N series.
