Mitsubishi FX3U Series User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
335
18 Other Extension Devices and Optional Units (External Dimensions and Terminal Arrangement)
18.1 Special Function Units/Blocks
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
IInput/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
18.1.17 FX2N-10GM
External Dimensions
•MASS(Weight): 0.3kg (0.66lbs)
•Installation: DIN rail of 35mm (1.38") in
width only can be used for
installation
•Accessories: FX
2NC-100MPCB power
cable, FX
2N-GM-5EC
extension cable, label for
indication of special unit/
block number, Manual
supplied with product
•Terminal block:
Connector
Terminal Layout
18.1.18 FX2N-20GM
External Dimensions
•MASS(Weight): 0.4kg (0.88lbs)
•Installation: DIN rail of 35mm (1.38") in
width only
•Accessories: FX
2NC-100MPCB power
cable, FX2NC-100BPCB
power cable, FX
2N-GM-5EC
extension cable, label for
indication of special unit/
block number,
Manual supplied with product
•Terminal block: Connector
Terminal Layout
74(2.92")
90(3.55")
Unit:mm (inches)
13(0.52")60(2.37")
X0
X1
X2
X3
Y0
Y1
Y2
Y3
COM1
Y5
START
STOP
ZRN
FWD
RVS
DOG
LSF
LSR
COM1
Y4
CON1
SVEND
COM2
PG0
COM4
RP
VIN
VIN
COM5
ST2
SVRDY
COM2
CLR
COM3
FP
VIN
VIN
COM5
ST1
Notch
CON2
74(2.92")
90(3.55")
Unit:mm (inches)
13(0.52")86(3.39")
X00
X01
X02
X03
X04
X05
X06
X07
COM1
Y00
Y01
Y02
Y03
Y04
Y05
Y06
Y07
COM1
CON1
START
STOP
ZRN
FWD
DOG
LSF
LSR
COM1
START
STOP
ZRN
FWD
DOG
LSF
LSR
COM1
CON2
SVEND
COM2
PG0
COM4
RP
VIN
VIN
COM5
ST2
SVRDY
COM2
CLR
COM3
FP
VIN
VIN
COM5
ST1
CON3
SVEND
COM6
PG0
COM8
RP
VIN
VIN
COM9
ST4
SVRDY
COM6
CLR
COM7
FP
VIN
VIN
COM9
ST3
CON4
RVSRVS
Notch
X axisY axis (X axis) (Y axis)
