FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
106
6 Examination of System Configuration
6.8 Number of Input/Output (Occupied) Points and Current Consumption
6.8.5 [E] Special extension devices
1. Special function blocks
*1. When the voltage of the external DC power supply is 24V DC and 5V DC, the current is 70 mA and
100 mA, respectively.
*2. This block cannot be used together with FX
2N-32ASI-M.
The following number of points is added according to the products connected to the network.
Number of remote I/O stations × 32 points
*3. The following number of points is added according to the products connected to the network.
Total number of input/output points of remote I/O stations
*4. The number of points varies according to the products connected to the network.
For details, refer to FX
2N-16LNK-M Manual.
*5. This block cannot be used together with FX
2N-16CCL-M. Only one unit can be added to the whole
system.
The following number of points is added according to the products connected to the network.
Number of active slaves × 8 points
*6. When analog special function blocks (FX
0N-3A, FX2N-2AD and FX2N-2DA) are connected to an input/
output powered extension unit (FX
2N-32E or FX2N-48E), the following limitation must be taken into
consideration. (When the blocks are connected to the main unit, this limitation is not applied.)
The total current consumption of the analog special function blocks (FX
0N-3A, FX2N-2AD and FX2N-
2DA) should be less than the following current values.
-
Total current consumption of blocks connected to FX2N-32E: 190 mA or less
- Total current consumption of blocks connected to FX2N-48E: 300 mA or less
*7. When applying the DC power type main unit, calculate the current consumption at startup.
No. Type
Number of
input/occupied
output points
Current consumed (mA) Current
supply at
startup [mA]
*7
5V DC Internal 24V DC External 24V DC
FX
3U-4AD 8 110 0 90 −
FX
3U-4DA 8 120 0 160 −
FX
3U-20SSC-H 8 100 0 220 −
FX
2N-2AD 8 20
50
*6
0 170
FX
2N-2DA 8 30
85
*6
0 190
FX
2N-4AD 8 30 0 55 −
FX
2N-4DA 8 30 0 200 −
FX
2N-4AD-TC 8 30 0 50 −
FX
2N-4AD-PT 8 30 0 50 −
FX
2N-8AD 8 50 0 80 −
FX
2N-5A 8 70 0 90 −
FX
2N-2LC 8 70 0 55 −
FX
2N-1HC 8 90 0 0 −
FX
2N-1PG(-E) 8 55 0 40 −
FX
2N-10PG 8 120 0
70
*1
−
FX
2N-232IF 8 40 0 80 −
FX
2N-16CCL-M
8
*2
0 0 150 −
FX
2N-32CCL 8 130 0 50 −
FX
2N-64CL-M
8
*3
190
Supplied from power supply for
CC-Link/LT
−
FX
2N-16LNK-M
0
*4
200 0 90 −
FX
2N-32ASI-M
8
*5
150 0 70 −
FX
0N-3A 8 30
90
*6
0 165
E
E1
E2
E3
To Next Page
