19 FX3U-7DM (Display Module)
19.11 Contrast
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
IInput/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
19.11 Contrast
The liquid crystal display contrast setting is specified at the "Contrast" menu. Selections made at this menu
are saved at D8302. A contrast setting of "0" is specified at factory default.
1) At the menu screen, use the [+] / [-] buttons to move the cursor to
the "Contrast" item, then press [OK] to display the "contrast
adjustment screen".
To cancel the operation and return to the "top screen (time
display)", press [ESC].
2) Use the [+] / [-] buttons to adjust the contrast.
To cancel the operation and return to the "menu screen", press
[ESC].
3) Press the [OK] button to register the selected setting and return to the "menu screen".
Button Operation Description
ESC Cancels the operation and returns to the "menu screen".
-
Lowers the contrast
(decreases the numeric value. The value can be decreased to -5.)
+
Increases the contrast
(increases the numeric value. The value can be increased to +10.)
OK Registers the selected setting and returns to the "menu screen".
Ctnora
(5-
0
10)~
st
(5-
3
10)~
Ctnorast
