FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
324
16 FX2N-8/16E*-*(Input/Output Extension Blocks)
16.13 FX2N-16EYS (Triac Output: 16 Points)
16.13.2 Parts identification and terminal arrangement
When an output (Y) number is assigned, 8 points on the upper side will be used for the lower output numbers,
and 8 points on the lower side will be used for the higher output numbers.
16.13.3 External dimensions
Y0
COM1
Y1
Y2
Y3
Y4
Y5 Y7Y6 Y0 Y1
Y2
Y3
Y4
Y5
Y6
Y7
COM2
Lower
numbers
Higher
numbers
Y0 Y2 Y4 Y2 Y4 Y6
COM2
Y7Y5Y3Y1Y0Y7Y6Y5Y3Y1
COM1
With cover
Output indicator
lamps
(LED lamps)
Output indicator
lamps
(LED lamps)
Without cover
Rear line
extension
connector
87(3.43")
80(3.15")
(mounting hole pitch)
90(3.55")
Unit:mm (inches)
9(0.36")
40(1.58")
2-φ4.5 mounting holes
