Mitsubishi FX3U Series User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
235
13 Examples of Wiring for Various Uses
13.5 Input Matrix [MTR Instructions (FNC 52)]
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
IInput/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
3. Input/output powered extension unit
Example of program
Examples of wiring
M8000
X060 Y050 M30 K3MTR
COM X060
COM1
X061 X062 X063 X064 X065 X066 X067
Y050 Y051 Y052 Y053 Y054 Y055 Y056 Y057
Transistor output (sink)
When a sink input type unit is used
M30 M31 M32 M33 M34 M35 M36 M37
M40 M41 M42 M43 M44 M45 M46 M47
X061 X062 X063 X064 X065 X066 X067
M50 M51 M52 M53 M54 M55 M56 M57
X061 X062 X063 X064 X065 X066 X067
FX 2N -32ET
FX
2N -48ET
In the case of sink wiring
0.1A 50V
diode is
necessary.
Input/output powered extension unit
24V X060
+V0
X061 X062 X063 X064 X065 X066 X067
Y050 Y051 Y052 Y053 Y054 Y055 Y056 Y057
Transistor output (source)
When a source input type unit is used
M30 M31 M32 M33 M34 M35 M36 M37
M40 M41 M42 M43 M44 M45 M46 M47
X061 X062 X063 X064 X065 X066 X067
M50 M51 M52 M53 M54 M55 M56 M57
X061 X062 X063 X064 X065 X066 X067
0.1A 50V
diode is
necessary.
0VS/S
FX 2N -32ET-ESS/UL
FX
2N -48ET-ESS/UL
In the case of source wiring
Input/output powered extension unit

Mitsubishi FX3U Series Specifications

General

Model	FX3U Series
Program Memory	64k steps
Execution Speed	0.065 μs/basic instruction
Type	PLC (Programmable Logic Controller)
Power Supply	100-240V AC
I/O Points	Up to 384
Communication	USB
Expansion	Supported via expansion modules
High-Speed Counters	Up to 6 channels
Analog Input/Output	Available via expansion modules
Temperature Range	0 to 55°C
Programming Language	Ladder Logic, Structured Text
Built-in Functions	PID control
Humidity	5 to 95% (non-condensing)
