Mitsubishi FX3U Series User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
239
13 Examples of Wiring for Various Uses
13.6 Seven Segment with Latch [SEGL Instructions (FNC74)/BCD Instructions (FNC18)]
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
IInput/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
2. Main unit and input/output powered extension units
Example of program
Examples of wiring
M8000
D100 K2Y020BCD
Y020COM1 Y021 Y022 Y023 Y024 Y025 Y026 Y027
12481248
8421 8421
Transistor output (sink)
Input/output powered extension unit
FX
2N -32ET
FX
2N -48ET
Signal
-
7-segment display
+
Y
COM1
PLC
7-segment display to be used for sink
wiring (in the case of transistor output)
In the case of sink wiring
Y020+V0 Y021 Y022 Y023 Y024 Y025 Y026 Y027
12481248
8421 8421
Transistor output (source)
Signal
-
7-segment display
+
Y
PLC
+V0
7-segment display to be used for source
wiring (in the case of transistor output)
Input/output powered extension unit
FX
2N -32ET-ESS/UL
FX
2N -48ET-ESS/UL
In the case of source wiring

Mitsubishi FX3U Series Specifications

General

Model	FX3U Series
Program Memory	64k steps
Execution Speed	0.065 μs/basic instruction
Type	PLC (Programmable Logic Controller)
Power Supply	100-240V AC
I/O Points	Up to 384
Communication	USB
Expansion	Supported via expansion modules
High-Speed Counters	Up to 6 channels
Analog Input/Output	Available via expansion modules
Temperature Range	0 to 55°C
Programming Language	Ladder Logic, Structured Text
Built-in Functions	PID control
Humidity	5 to 95% (non-condensing)
